Kodak NL2.5 Lithium Battery

The Kodak NL2.5 lithium battery module is a high-performance, modular energy storage solution designed for solar, hybrid, and off-grid systems. With a 24 V nominal voltage, deep cycle endurance, and excellent scalability, the NL2.5 is particularly suited for installations that demand reliable, long-lasting power storage with efficient charging and discharging.

• Energy Capacity & Nominal Power


  • 2.56 kWh (2,560 Wh) nominal energy.


  • Rated power of ~2,500 W continuous discharge.


• Scalable & Modular Design


  • Can be connected in parallel — up to 15 modules for a total of ~38.4 kWh storage.


  • Ideal for system expansion: start small and scale as your power needs grow.


• High Cycle Life


  • 6,000 cycles at 80% depth of discharge (DoD), making it suitable for high-cycle applications such as daily deep-discharge systems.


  • 80% DoD ensures you're using most of the capacity while maintaining longevity.


• Robust Charge / Discharge Performance


  • 1C charge and discharge rate – you can charge and draw current at up to the equivalent of its full capacity per hour.


  • Continuous charge / discharge current: up to 100 A.


  • Surge discharge (short bursts) supported: up to 2,880 W for 15 seconds.


• Voltage & Communications


  • Nominal voltage: ~24 V module (datasheet shows 25.6 V nominal) for compatibility with 24 V inverters.


  • Communication interfaces: CAN / RS-485 and RS-232.


  • This ensures seamless integration with a wide range of inverters, including Kodak 24V inverters.


• Durable & Safe Design


  • Closed-line design helps prevent dust or insects disrupting connections.


  • Built for long-term reliability and frequent cycling — particularly useful in solar + backup systems.


• Easy Installation


  • No extra mounting racks or brackets required, saving install time and complexity.


  • Plug-and-play design makes it relatively straightforward for installers.


• Depth of Discharge (DoD)


  • 80% DoD standard — gives a good balance between usable capacity and battery life.
